Network Cabinet Speakers
W8115
Professional Network Cabinet Speaker
PoE+ SIP 2.0 ONVIF
Enhance your IP audio with the W8115 Network Speaker. Supports PoE, triple SIP accounts, and 48K OPUS encoding. Durable and easy to install.
Sound Pressure 100dB Max
Frequency 80Hz - 18KHz
- Master-Slave Setup: Drive an additional 8Ω 15W passive sub-speaker directly from the main unit for broader coverage.
- Flexible Connectivity: Standard PoE support or external DC 24V 2A power supply for various installation scenarios.
- Protocol Harmony: Fully compatible with SIP phone systems and VMS via ONVIF for seamless management.
Crystal Clear Audio
With 48K OPUS encoding and a wide 80Hz - 18KHz response, the W8115 is perfect for high-quality background music and intelligible paging.
Master-Slave Extension
Significantly reduce installation costs by connecting a passive sub-speaker to a single IP active cabinet speaker unit.
Smart Integration
Supports 3 SIP accounts and HTTP API for flexible alarms. Native ONVIF support for VMS software management.
Detailed Specifications
| Model | W8115 |
| Amplifier | Built-in 15W Amplifier |
| Frequency Range | 80Hz - 18KHz |
| Max Sound Pressure | 100dB |
| Power Supply | PoE (IEEE 802.3af/at) or DC 24V 2A |
| Audio Codecs | 48K OPUS, G.711, G.722, L16 |
| SIP Accounts | 3 Accounts |
| External Output | Drive 8Ω 15W Passive Sub-speaker |
| Management | SIP 2.0, ONVIF, HTTP API |
Looking for a customized hardware version?
We support OEM/ODM requests including custom LOGO, PCB redesign, and specific feature adaptation.
Start My Project
